Double-Beam Four-Wheel Drive Unit
* Delivers a field utilization rate exceeding 98%, effectively eliminating unirrigated corners associated with center pivot irrigation
* Ideally suitable for rectangular or narrow land plots
* Effective for irrigating cash crops such as grains, vegetables, sugarcane, orchards, and nurseries, and supports fertigation
* Equipment reaches maximum length of 800 meters with maximum travel distance of 3,000 meters, irrigating up to 240 hectares per unit
* On-site installation support and technical guidance provided
Double-Beam Four-Wheel Drive Unit for Linear Irrigation Systems
Anhui Showy Agricultural Irrigation Technology Co., Ltd. manufactures the Double-Beam Four-Wheel Drive Unit specifically engineered for linear irrigation applications. This unit enables straight-line travel perpendicular to equipment structure, delivering exceptional performance on level terrain with field utilization rates exceeding 98%. Operating across maximum lengths of 800 meters and travel distances reaching 3,000 meters, each unit can irrigate up to 240 hectares. With a 34,000-square-meter professional workshop and annual capacity of 1,800 center pivot and linear systems, our facility ensures reliable supply for modern agricultural operations worldwide.
Superior Design for Rectangular Field Coverage
The corner waste that is characteristic of circular designs is eliminated by linear irrigation systems. In a variety of soil conditions, the four-wheel drive setup offers improved traction and stability.
Irrigation coverage rates exceeding 98% are advantageous for your narrow or rectangular land holdings. For fields with length-to-width ratios larger than 2:1, when conventional center pivot systems leave sizable unirrigated patches, this design works very well.
By distributing weight uniformly, the double-beam structure minimizes soil compaction while preserving exact alignment while in use. This innovative method preserves your priceless crops while increasing equipment longevity.
Technical Specifications
| Product Model | JP-75/300 | JP-75/400 | JP-75/500 | JP-90/300 | JP-90/400 |
|---|---|---|---|---|---|
| PE Pipe Diameter (mm) | 75 | 75 | 75 | 90 | 90 |
| PE Pipe Length (m) | 300 | 400 | 500 | 300 | 400 |
| Effective Irrigation Length (m) | 300 | 400 | 500 | 300 | 400 |
| Inlet Pressure (MPa) | 0.5-1 | 0.5-1 | 0.6-1.1 | 0.5-1 | 0.3-1.2 |
| Nozzle Diameter | 16-22 | 16-22 | 16-22 | 18-24 | 14-28 |
| Nozzle Pressure (MPa) | 0.25-0.5 | 0.25-0.5 | 0.25-0.5 | 0.4-0.6 | 0.25-0.5 |
| Sprinkler Flow Rate (m³/h) | 15.5-34.3 | 15.5-34.3 | 15.5-34.3 | 17.2-48.4 | 10-50 |
| Spray Range (m) | 24-44 | 24-44 | 24-44 | 24-46 | 25-46 |
| Irrigation Width (m) | 47-74 | 47-74 | 47-74 | 43-78 | 43-78 |
| Travel Speed (m/h) | 8-60 | 8-60 | 8-60 | 10-80 | 10-80 |
| Application Rate (mm/h) | >7 | >7 | >7 | >8 | >8 |
Intelligent Automation Features
Your team will find the Double-Beam Four-Wheel Drive Unit easy to use due to its high automation levels. Throughout irrigation cycles, the automatic brake system maintains a constant rotation speed by adjusting brake force in reaction to changes in pressure and flow.
Fertigation can be easily integrated with these systems. Accurate control maximizes crop uptake and minimizes fertilizer waste by coordinating nitrogen delivery with water application.
Performance is regularly monitored by the centralized control system. Even when field conditions change throughout your irrigated area, real-time changes guaranty consistent water distribution.
Proven Durability and Performance
Long-lasting machine parts have an average service life of more than ten years. Under typical operating conditions, PE pipes retain their structural integrity for more than 15 years.
With savings of more than 50% when compared to conventional flood irrigation, your water management significantly improves. Increased crop yields and lower operating costs are closely correlated with these efficiency increases.
From grain production to vegetables, sugarcane, orchards, and nurseries, each unit efficiently manages a variety of applications. Because of its adaptability, your investment can change as cropping patterns do.
Comprehensive Support Services
Every system delivery is accompanied by technical assistance and on-site installation support. Our skilled professionals guaranty appropriate setup based on your unique crop needs and field conditions.
Our integrated service network provides you with continuous support. Our staff offers professional solutions that maintain the optimal performance of your irrigation system, from product customisation to troubleshooting.
We uphold strict quality standards at our 60,000-square-meter production site in Anhui. We support our equipment with a track record of manufacturing excellence as a National Intellectual Property Advantageous Enterprise and Agricultural Machinery Science and Technology award winner.
Frequently Asked Questions
Q: How does the high irrigation coverage rate benefit my rectangular fields?
A: Linear systems are specifically designed for rectangular fields with length-to-width ratios greater than 2:1, achieving coverage rates over 98%. This eliminates unirrigated corners and maximizes your productive acreage.
Q: Can I integrate fertigation with this system?
A: Absolutely. The high degree of automation makes these units ideal for fertigation integration, allowing precise nutrient delivery synchronized with irrigation schedules for optimal crop nutrition.
Q: What quality guarantees support my investment?
A: The automatic brake system ensures efficient operation by adjusting brake force according to pressure and flow variations. This maintains consistent performance across the entire field, even under fluctuating conditions.
Q: What products and parts are available for maintenance?
A: You can purchase drive motors, gearboxes, couplers, and various system components. Our comprehensive parts inventory supports long-term maintenance with customizable options for your specific needs.
Q: Are you a direct manufacturer?
A: Yes, we are a professional manufacturer with many years specializing in irrigation equipment. Our modern facility in Anhui, China features advanced manufacturing equipment and strict quality management. We welcome factory visits anytime.
Contact Us for Customized Solutions
Ready to optimize your field irrigation efficiency with our Double-Beam Four-Wheel Drive Unit? Contact kevin@showyirrigation.com today for expert consultation and tailored system design for your agricultural operation.
Get a tailored irrigation solution for your project — our engineering team is ready to support you from design to installation.
