Boom Back Dry Wheel Track Solution

Boom Back Dry Wheel Track Solution  Superior Engineering for Modern Pivot Irrigation

Anhui Showy Agricultural Irrigation Technology Co., Ltd. delivers an advanced Boom Back Dry Wheel Track Solution featuring hot-dip galvanized construction with a minimum zinc coating thickness of 80μm for exceptional corrosion resistance. Engineered within a 34,000-square-meter professional workshop, this solution operates at a maximum radius of 800 meters, covering irrigated areas up to 200 hectares. The SAIT system aligns precisely with soil infiltration characteristics, offering standard, low, high, and ultra-high profile configurations. With a truss rod and angle framework design, the solution ensures balanced load distribution across spans, delivering over 20 years of reliable service life.

What Makes This Solution Essential?

This specialized irrigation engineering configuration relocates water application behind the drive towers of center pivot and linear move systems. By utilizing directional boom extensions constructed from galvanized steel, the solution keeps soil directly in the path of drive wheels dry during irrigation cycles.

Your operation benefits from eliminating critical pain points. Stuck pivots, deep soil rutting, and excessive drivetrain wear caused by high-torque requirements in muddy conditions become concerns of the past. The wetted perimeter shifts 180 degrees relative to travel direction, maintaining structural integrity and operational uptime in heavy soil textures.

Technical Specifications

Key Performance Advantages

Your Boom Back Dry Wheel Track Solution provides documented reduction in wheel track depth by 60-80%. This significantly lowers rolling resistance and energy consumption of drive motors.

Water Efficiency: You save over 70% more water compared to traditional flood irrigation. A single unit irrigates 4 to 200 hectares per cycle with integrated water-fertilizer operation for maximized efficiency.

Durability Standards: Hot-dip galvanized coating adheres to ISO 1461 standards, providing excellent rust prevention. The design ensures a service life of 20 years or more, withstanding structural harmonics and wind loads in open agricultural environments.

Intelligent Automation: Remote control, irrigation scheduling, and zone-based irrigation operate through the SAIT Smart Control System. Big data models enable precision Variable Rate Irrigation integrated with smart agriculture platforms.

Critical Application Scenarios

Heavy Clay Soil Management: In regions with high-plasticity clay, this solution prevents the suction effect that traps pivot tires. Your operation continues without manual intervention.

Precision Variable Rate Irrigation: When water application depths vary frequently in VRI setups, boom backs ensure increased water volume in specific zones doesn't compromise path stability of your machinery.

Undulating Topography: On steep slopes where runoff typically accumulates in wheel tracks, the system provides necessary traction for drive units. You climb grades exceeding 15% without slippage, ensuring consistent application across complex landscapes.

Quality Assurance & Standards

Anhui Showy maintains rigorous quality control aligned with industry certifications. As a National Intellectual Property Advantageous Enterprise, we've earned the First Prize of Agricultural Machinery Science and Technology and the First Prize of Agricultural Water-Saving Science and Technology Award.

Our inspection protocols include weld integrity testing using ultrasonic methods, pressure regulation accuracy testing at 10-20 PSI, and galvanization thickness measurement meeting ASTM A123 standards. Clamp torque analysis ensures mounting brackets remain secure under dynamic loads.

With an annual production capacity of 1,800 sets of center pivot and linear irrigation systems from our 60,000-square-meter facility, you receive stable supply backed by comprehensive engineering support.

​​​​​​​

Frequently Asked Questions

Q: Does the system affect Coefficient of Uniformity (CU)?
A: When professionally engineered with proper nozzle spacing and overlap calculations, impact on CU remains negligible, typically staying within the 85-90% industry-standard range.

Q: Can it be retrofitted to older pivot models?
A: Yes. Universal mounting kits allow integration with most major OEM spans regardless of pipe diameter.

Q: How does it perform in high winds?
A: The low-profile design and rigid plumbing minimize wind-induced sway compared to flexible drop hoses.

Q: What maintenance is required?
A: Annual inspection of mounting hardware and periodic flushing of boom-end caps to remove sediment keeps your system running optimally.

Q: What is the expected ROI?
A: Most operations see returns within 1-3 seasons through reduced labor costs for towing stuck equipment and extended gearbox and tire life.

Contact Us for Expert Guidance

Ready to optimize your irrigation efficiency? Reach out to our technical team at kevin@showyirrigation.com for customized Boom Back Dry Wheel Track Solution solutions and professional support.
