Media Filter – Advanced Filtration Solution for Precision Agriculture

Anhui Showy Agricultural Irrigation Technology Co., Ltd. delivers enterprise-grade Media filter systems designed for integrated automatic irrigation and fertigation applications. Our filtration solutions feature DN100 centrifugal filters combined with DN100 automatic self-cleaning filters, offering 120/130 mesh filtration accuracy.

These systems manage working pressures between 0.2 and 0.7 MPa while processing flows thru DN200 inlet/outlet connections. They were designed for large-scale open fields, orchards, and greenhouse operations. Our 34,000-square-meter production facility, which can produce 1,800 irrigation systems a year, ensures dependable performance supported by national water-saving certification.

Your investment in precision farming equipment is protected by our cutting-edge filtering technology.

What Makes Our Filtration Systems Different

The Media filter technology removes suspended particles and organic matter before they reach sensitive irrigation components. This depth filtration approach captures contaminants throughout the filter bed rather than just at the surface.

Your spray nozzles and drip emitters remain cleaned for longer. By keeping downstream equipment from being clogged, the system lowers the frequency of maintenance.

Centrifugal pre-separation and automated backwashing are combined in our dual-stage filtration. Without human involvement, this setup manages fluctuating water quality conditions.

Complete System Integration

The smart head control system combines fertilizer injection, filtration, and pump control into a single, small device. The dimensions, which fit conventional equipment shelters, are 3000 x 2300 x 2500 mm.

An 11kW pressure pump with variable frequency drive control is included. Smart energy monitoring and 80kA surge protection are features of the three-phase 380VAC system.

4G wireless connectivity allows for remote operation. Local control is provided by the 10-inch touchscreen, and field-to-office visibility is provided by your mobile app.

Technical Specifications

Key Performance Benefits

Your Media filter system operates automatically with minimal supervision. The self-cleaning mechanism initiates backwash cycles based on differential pressure readings or timed intervals.

High-quality stainless steel construction resists corrosion in fertilizer-laden water. The fully enclosed design meets IP55 standards for dust and water ingress protection.

The system adapts to varying irrigation flow rates and pressure conditions. Intelligent controls adjust pump speed and filter operation to match real-time demand.

You'll reduce chemical costs through precise fertilizer injection ranging from 10-100% of maximum capacity. The ultrasonic flow measurement ensures accurate nutrient delivery rates.

Smart Automation Capabilities

All filtration and fertigation operations are controlled by the ARM9-based controller. Reliability in challenging agricultural conditions is ensured by industrial-grade EMC/ESD protection.

The 1024x600 resolution touchscreen allows your staff to keep an eye on system performance. Pressure levels, flow rates, and fertilizer usage are displayed in real-time.

You can change settings remotely from any location using the mobile app. Reminders for maintenance and status updates are sent straight to your phone via the 4G connection.

Weather stations and soil moisture sensors are connected to several RS485 interfaces. Truly automated irrigation scheduling based on actual crop needs is made possible by this integration.

​​​​​​​

Frequently Asked Questions

Q: How does the automatic backwash system work?
A: The controller monitors differential pressure across the filtration unit. When pressure drop exceeds your preset threshold, the system initiates a backwash cycle that reverses flow to clean the filter media without stopping irrigation operations.

Q: What filtration maintenance does the system require?
A: Check and clean the centrifugal pre-filter weekly during peak season. Inspect filter screens monthly for damage. The automatic system handles routine cleaning, but quarterly professional inspection ensures optimal performance.

Q: Can the system handle different water sources?
A: Yes, the dual-stage filtration processes well water, surface water, and treated wastewater. Adjust backwash frequency based on your source water quality. The 120/130 mesh accuracy removes particles that damage drip systems.

Q: What fertilizer types work with this system?
A: The injection system handles both liquid and fully dissolved solid fertilizers. Use fertilizers with complete solubility to prevent crystallization in lines. The stainless steel pump resists corrosion from acidic or alkaline formulations.

Q: How do I determine proper system sizing?
A: Calculate your peak irrigation flow rate and choose inlet/outlet connections accordingly. The DN200 configuration handles large field systems. Contact our technical team for assistance matching filtration capacity to your specific operation.

Contact Us for Custom Solutions

Ready to upgrade your irrigation water quality with premium Media filter solutions? Our engineering team provides site-specific system design and professional installation support. Reach us at kevin@showyirrigation.com for technical consultation and pricing.
