Single-Beam Four-Wheel Drive Unit
* Achieves field utilization rate exceeding 98%, effectively eliminating unirrigated corners typical of center pivot systems
* Ideally suited for rectangular or narrow field configurations
* Effective for irrigating cash crops including grains, vegetables, sugarcane, orchards, and nurseries, and compatible with fertigation
* Maximum equipment length of 800 meters with travel distance up to 3,000 meters, covering up to 240 hectares per unit
* On-site installation support and technical guidance supplied
Single-Beam Four-Wheel Drive Unit for Linear Irrigation Systems
Anhui Showy Agricultural Irrigation Technology Co., Ltd. presents its advanced Single‑Beam Four‑Wheel Drive Unit engineered specifically for linear irrigation systems. This precision‑designed unit operates perpendicular to equipment frames, achieving exceptional field utilization rates exceeding 98% on level terrain. Our manufacturing facility spans 34,000 square meters with annual production capacity reaching 1,800 sets of linear irrigation equipment. It covers up to 240 hectares per installation with maximum equipment length of 800 meters and travel distance extending to 3,000 meters, delivering unmatched irrigation efficiency for modern agricultural operations.
What Makes Our Linear Drive Unit Superior
In both rectangle and narrow field configurations, the four-wheel drive setup guaranties consistent traction distribution. For commercial crops including cereals, vegetables, sugarcane, orchards, and nurseries, this synchronized power supply removes the unirrigated corners common to center pivot systems.
Robust design and clever automation are beneficial to your irrigation system. Depending on the model you choose, the device may deliver precise water application rates of more than 7-8 mm per hour while traveling at speeds between 8 and 80 meters per hour.
Technical Specifications
| Model | JP-75/300 | JP-75/400 | JP-75/500 | JP-90/300 | JP-90/400 |
|---|---|---|---|---|---|
| PE Pipe Diameter (mm) | 75 | 75 | 75 | 90 | 90 |
| PE Pipe Length (m) | 300 | 400 | 500 | 300 | 400 |
| Effective Irrigation Length (m) | 300 | 400 | 500 | 300 | 400 |
| Inlet Pressure (MPa) | 0.5-1 | 0.5-1 | 0.6-1.1 | 0.5-1 | 0.3-1.2 |
| Nozzle Diameter | 16-22 | 16-22 | 16-22 | 18-24 | 14-28 |
| Nozzle Pressure (MPa) | 0.25-0.5 | 0.25-0.5 | 0.25-0.5 | 0.4-0.6 | 0.25-0.5 |
| Sprinkler Flow Rate (m³/h) | 15.5-34.3 | 15.5-34.3 | 15.5-34.3 | 17.2-48.4 | 10-50 |
| Spray Range (m) | 24-44 | 24-44 | 24-44 | 24-46 | 25-46 |
| Irrigation Width (m) | 47-74 | 47-74 | 47-74 | 43-78 | 43-78 |
| Travel Speed (m/h) | 8-60 | 8-60 | 8-60 | 10-80 | 10-80 |
| Application Rate (mm/h) | >7 | >7 | >7 | >8 | >8 |
Key Performance Advantages
With an average machine service life of more than ten years, your investment yields long-term value. For more than 15 years, the structural integrity of the PE pipe components is maintained, guaranteeing low replacement costs over the operational duration.
When compared to conventional irrigation techniques, water conservation reaches astounding levels with savings of more than 50%. Increased crop yields and lower operating costs for your farming operations are direct results of this efficiency.
The capacity for coverage is likewise remarkable. For large-scale agricultural businesses, a single unit may irrigate more than 1.33 hectares every cycle, increasing productivity and reducing manpower needs.
Automation and Fertigation Integration
High automation capabilities make this Single‑Beam Four‑Wheel Drive Unit linear drive system perfect for fertigation applications. The automatic brake system continuously adjusts brake force according to pressure and flow variations, maintaining consistent rotation speed across your entire field even under fluctuating conditions.
Three configuration options accommodate diverse field layouts: Swing-Around Linear Irrigation, Four-Wheel Lateral Irrigation, and Two-Wheel Linear Irrigation. You can select the optimal configuration based on your specific terrain and crop requirements.
The intelligent control system ensures efficient operation throughout the growing season, reducing manual intervention while maintaining precise water and nutrient delivery to your crops.
Available Product Range and Support
You can buy complete irrigation components, such as UMC® drive motors, precision gearboxes, sturdy couplers, and other pivot system components, in addition to our linear drive units. In our accredited production facility, every component is put thru stringent quality testing.
Your particular agricultural problems are taken care of by our customisation services. To maximize your irrigation infrastructure, technical support teams offer professional advice during the equipment selection, installation, and operation stages.
Every purchase is accompanied by expert assistance and on-site installation support, guaranteeing that your system operates at peak efficiency from initial commissioning thru years of dependable operation.
Partner With Industry Leaders
We drive the development of irrigation industry standards as a subsidiary of Huayuan Water Saving and an accredited National Intellectual Property Advantageous Enterprise. Our knowledge influences irrigation pipeline specifications and hose-reel irrigation standards utilized in the agriculture industry.
Our dedication to quality and client pleasure is demonstrated by our designation as one of China's Most Favorable Agricultural Machinery Brands. Consistent innovation and dependable performance throughout thousands of installations globally are the foundation of this reputation.
Frequently Asked Questions
Q: Why does linear irrigation achieve 98% coverage?
A: Linear systems are specifically designed for rectangular fields with length-to-width ratios greater than 2:1. The perpendicular travel path eliminates the corner gaps inherent in circular pivot systems, delivering comprehensive field coverage.
Q: How does quality control ensure reliable performance?
A: Our manufacturing facility implements strict quality management protocols aligned with industry standards. Each system undergoes comprehensive testing before shipment, including pressure testing, flow verification, and structural integrity inspection.
Q: Can your system handle different crop types?
A: Absolutely. The variable travel speed and adjustable nozzle configurations accommodate diverse crop requirements from low-growing vegetables to tall sugarcane varieties. Fertigation compatibility further enhances versatility across multiple agricultural applications.
Q: Are you a manufacturer or trading company?
A: We operate as a specialized manufacturer with decades of irrigation equipment expertise. Our modern production facility in Anhui, China features advanced manufacturing equipment and strict quality controls. We welcome factory visits to demonstrate our production capabilities firsthand.
Q: What ongoing services do you provide?
A: Comprehensive post-purchase support includes technical consultation, spare parts availability, operational training, and system optimization guidance. Our commitment extends throughout your equipment's entire service life.
Contact Us Today
Ready to transform your irrigation efficiency? Contact our team at kevin@showyirrigation.com for customized Single‑Beam Four‑Wheel Drive Unit solutions tailored to your agricultural needs. Let's optimize your water management together.
Get a tailored irrigation solution for your project — our engineering team is ready to support you from design to installation.
